| Air flow at 1 speed - extractor by EN 61591 337 m3/h |
Air flow at 2 speed - extractor by EN 61591 377 m3/h |
Air flow at 3 speed - extractor by EN 61591 397 m3/h |
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 397 m3/h |
Air Flow at Minimum Speed in Normal Use 337 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 213.6 m3/h |
| Air Pressure at Best Efficiency Point P BEP 139 Pa |
Annual energy consumption 65 kWh |
Annual energy consumption 65 kWh |
| Average Illumination of the Lighting System on the Cooking Surface - E middle 265 lux |
Control panel on one side/two sides One side |
Country of Origin on Rating Label Made in Poland |
| Dimensions of grease filter 200x496x9mm |
Display color Red |
Distance from light cover to wall 10 mm |
| Distance to electric hob 450 mm |
Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 98.2 W |
| Fluid Dynamic Efficiency - FDE hood 8.7 |
Fluid Dynamic Efficiency Class E |
Grease Filtering Efficiency - GFE hood 73.6 % |
| Grease Filtering Efficiency Class D |
Internal/external motor Internal |
Lighting Efficiency - LE hood 35.3 lux/W |
Lighting Efficiency Class A |
Lighting Efficiency Class A |
Maximum Possible Air Flow 397 m3/h |
Motor unit rated power 120 W |
Motor type/model K-42 010 02 HE CW (Obudowa Gorenje SLS |
Net depth 320 mm |
Net height max 173 mm |
Net height min 173 mm |
Net weight 7.4 kg |
Net width 600 mm |
Noise level at 1 speed - extractor by EN 60704-2-13 68 dB |
Noise level at 2 speed - extractor by EN 60704-2-13 73 dB |
Noise level at 3 speed - extractor by EN 60704-2-13 75 dB |
Nominal Power of the Lighting System - W L 7.5 W |
Number of motor units 1 |
Number units of main lighting 2 |
Air exhaust diameter 150 mm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.25 W |
Power cabel length 150 cm |
Power rating 126 W |
Power Supply Voltage 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 75 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 68 dB |
Noise level 75 dB |
Time Increase Factor - f 1.7 |
Type of main lighting LED |
