| Air flow at 1 speed - extractor by EN 61591 144 m3/h |
Air flow at 2 speed - extractor by EN 61591 205 m3/h |
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 205 m3/h |
| Air Flow at Minimum Speed in Normal Use 144 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 117.1 m3/h |
Air Pressure at Best Efficiency Point P BEP 157 Pa |
| Annual energy consumption 54.6 kWh |
Annual energy consumption 54.6 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 61 lux |
| Control panel on one side/two sides One side |
Country of Origin on Rating Label Made in EU |
Dimensions of grease filter 200x496x9 |
| Display color No |
Distance from light cover to wall 20 mm |
Distance to electric hob 650 mm |
| Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 78.4 W |
Fluid Dynamic Efficiency - FDE hood 6.5 |
| Fluid Dynamic Efficiency Class F |
Grease Filtering Efficiency - GFE hood 68.5 % |
Grease Filtering Efficiency Class D |
| Internal/external motor Internal |
Lighting Efficiency - LE hood 14.5 lux/W |
Lighting Efficiency Class D |
Lighting Efficiency Class D |
Maximum Possible Air Flow 205 m3/h |
Motor unit rated power 90 W |
Motor type/model K-23 008 01 HE |
Net depth 310 mm |
Net height max 170 mm |
Net height min 170 mm |
Net weight 6.7 kg |
Net width 600 mm |
Noise level at 1 speed - extractor by EN 60704-2-13 57 dB |
Noise level at 2 speed - extractor by EN 60704-2-13 65 dB |
Nominal Power of the Lighting System - W L 4.2 W |
Number of motor units 1 |
Number units of main lighting 1 |
Air exhaust diameter 120 mm |
Type of plug or cable Euro plug |
Power cabel length 220 cm |
Power rating 94 W |
Power Supply Voltage 230V |
Power unit of main lighting 4 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 65 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 57 dB |
Noise level 65 dB |
Time Increase Factor - f 1.8 |
Type of main lighting LED |
